Gearbox is made of graphite casting iron. Material performance is better. Not easy broken.
Product Attribute:
1. Transmission: chain driven.
2. Gearbox is made of graphite casting iron. Material performance is better. Not easy broken.
3. The suspension plate shape is not easy to deform.
4. Chain device hand adjustable. More easy and reliable.
5. Side protection plates are added onto the rear deflection. This device prevents the soil flying out.
6. The tilling height can be adjustable.
7. The structure is firm and stable
Specification:
1. 3 point linkage
2. Graphite casting iron gearbox
3. Tractor power required: 15-35hp / 20-45hp/50-100hp
| Model | Matched horse power(hp) | Blade qty(pcs) | Weight(kg) | Delivery size(m) |
| NKXG-100 | 18-20 | 22 | 180 | 1.1*0.7*0.7 |
| NKXG-125 | 25 | 26 | 190 | 1.3*0.7*0.7 |
| NKXG-140 | 25-30 | 30 | 200 | 1.5*0.7*0.7 |
| NKXG-150 | 25-30 | 34 | 210 | 1.6*0.7*0.7 |
| NKXG-160 | 30-40 | 38 | 230 | 1.7*0.7*0.7 |
| NKXG-180 | 50-55 | 42 | 350 | 1.9*0.75*0.75 |
| NKXG-200 | 55-75 | 46 | 370 | 2.1*0.75*0.75 |
| NKXG-220 | 60-80 | 50 | 390 | 2.3*0.75*0.75 |
| NKXG-250 | 70-90 | 58 | 420 | 2.6*0.75*0.75 |
| NKXG-300 | 80-90 | 70 | 480 | 3.1–*0.75*0.75 |
